Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 33413 |
| Body Style | Puck |
| Connection Type | QD Integral |
| Current, Leakage | 1 μA @ 30 VDC (OFF State) |
| Current, Switching | 150 mA |
| Diameter, Body | 18 |
| Housing Material | Thermoplastic |
| Humidity | 90% @ 50 C |
| Indicator | LEDs |
| Input Output | Discrete |
| IP Rating | IP69K |
| Light Source | Infrared LED |
| Material, Lens | Acrylic |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 0.1 m |
| Mechanical Angle | 3 |
| Minimum Operating Temperature | -40 C |
| Mounting Type | M18 Threaded |
| NEMA Rating | NEMA 6P |
| Number of Pins | 4 |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -40 C |
| Operation | Dark-ON/Light-ON |
| Output | NPN |
| Output Current | 150 mA (Max.) |
| Repeatability | 3 μs |
| Response Time | 3 ms |
| Sensing Mode | Background Suppression Fixed |
| Sensing Range | 100 |
| Series | |
| Standards | CE Marked, CSA Certified, UL Listed |
| Supply Voltage | 10-30 VDC |
| Technology | Photoelectric |
| Time, Turn-On Delay | 100 ms |
| Type | Reflective Sensors |
Overview
Features:
